Physical Design Engineering Services
At Sanketh Semiconductors, we specialize in end-to-end Physical Design implementation from RTL to GDSII for complex SoCs across advanced process nodes (7nm/5nm). Our team of certified physical design engineers delivers optimized PPA (Power, Performance, Area) results through proven methodologies and cutting-edge EDA tools from Synopsys and Cadence.
With 85+ successful tapeouts, we've developed expertise in floorplanning, power planning, placement, clock tree synthesis, routing, and signoff for high-performance computing, automotive, and AI/ML applications. Our ISO 9001:2015 certified processes ensure first-time-right silicon while meeting aggressive time-to-market requirements.
We partner with leading foundries to implement design rule compliant layouts with advanced DFM techniques. Our engineers are skilled in low-power design methodologies including multi-voltage domains, power gating, and dynamic voltage frequency scaling for energy-efficient silicon.
Our Physical Design Flow
Our comprehensive physical design methodology ensures optimal results at every stage:
- RTL synthesis with power-aware constraints
- Floorplanning with hierarchical design partitioning
- Power grid synthesis and IR drop analysis
- Clock tree synthesis with useful skew optimization
- Global and detailed routing with DRC-clean results
- Signoff-quality STA, EMIR, and physical verification
Key Differentiators
What sets our Physical Design services apart:
- Proven expertise in advanced FinFET nodes (7nm/5nm)
- Automotive-grade designs meeting ISO 26262 requirements
- High-speed interface implementation (DDR, PCIe, SerDes)
- DFT-aware physical implementation flow
- EM/IR-driven methodology for power integrity
Our team has successfully delivered complex SoCs with over 500M gates, achieving industry-leading performance metrics while optimizing for manufacturability and yield. Partner with us for your next physical design challenge.
